Icom IC-M25 User Manual

21
7
SET MODE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Floats and Flashes Alarm function ❏ “FLAr”
Alarm periodically sounds while the transceiver is floating in
the water, to allow you to find the transceiver in the water.
•OFF: ThefunctionisOFF.
•ON: Alarm periodically sounds while the transceiver is
floating in the water. This function stops when a
key is pushed or 10secondshavepastafterthe
transceiver is retrieved from the water.
CAUTION: The alarm sounds loudly.
Automatic AquaQuake function ❏ “AquA”
This function automatically activates the AquaQuake Water
Draining function when the transceiver is retrieved from the
water.
•OFF: ThefunctionisOFF.
•2/5/10:TheAquaQuakeWaterDrainingfunctionis
automatically activated after stopping the floating
alarm sound. A low vibration tone sounds for the
speciedtimeof2,5or10seconds,toremove
water from the speaker grill.
NOTE: This function does not activate when an external
speaker microphone is connected.
OFF (default) 2
Push
Alarm OFF (default) Alarm ON
Push

Icom IC-M25 Specifications

General

Battery type	BP-282
Battery life (max)	11 h
Battery low indication	Yes
Number of batteries supported	1
Purpose	Marine Radio Service
Operating frequency	156.025 - 157.425 MHz
Display type	LCD
USB connector type	Micro-USB B
Antenna connector type	FA-SC59V
Product color	Black, White
Waterproof up to	1 m
International Protection (IP) code	IPX7
Operating temperature (T-T)	-20 - 60 °C
Number of batteries included	1 pc(s)

Weight and Dimensions

Depth	30.5 mm
Width	56.6 mm
Height	134.2 mm
Weight	220 g
