Icom IC-M25 User Manual

ii
FOREWORD
Thank you for choosing this Icom product.
The IC-M25/IC-M25EURO
v h f m a r i n e t r a n s c e i v e r is
designed and built with Icom’s state of the art technology
and craftsmanship. With proper care, this product should
provide you with years of trouble-free operation.
IMPORTANT
READ ALL INSTRUCTIONS carefully and
completely before using the transceiver.
SAVE THIS INSTRUCTION MANUAL—This
instruction manual contains important operating instructions
for the IC-M25/IC-M25EURO.
EXPLICIT DEFINITIONS
WORD DEFINITION
RDANGER!
Personal death, serious injury or an explo-
sion may occur.
RWARNING!
Personal injury, fire hazard or electric
shock may occur.
CAUTION
Equipment damage may occur.
NOTE
If disregarded, only inconvenience. No risk
of personal injury, fire or electric shock.
FEATURES
☞ Floats on water
The transceiver floats in fresh or
salt water even when the supplied
accessories are attached.
 •Itmaysinkwhenathird-partyaccessoryis
attached.
☞ Floats and flashes
An LED sends out intermittent light from
a transparent section on the bottom
of the transceiver, while floating in the
water.
As the LED light stands out in the dark,
the transceiver can be easily retrieved
from the water.
This function works even when the transceiver is turned OFF.
☞ Floats and flashes alarm
An alarm sounds when the transceiver
is dropped into the water so that you
can know that the transceiver has fallen
in the water.

Icom IC-M25 Specifications

General

Battery type	BP-282
Battery life (max)	11 h
Battery low indication	Yes
Number of batteries supported	1
Purpose	Marine Radio Service
Operating frequency	156.025 - 157.425 MHz
Display type	LCD
USB connector type	Micro-USB B
Antenna connector type	FA-SC59V
Product color	Black, White
Waterproof up to	1 m
International Protection (IP) code	IPX7
Operating temperature (T-T)	-20 - 60 °C
Number of batteries included	1 pc(s)

Weight and Dimensions

Depth	30.5 mm
Width	56.6 mm
Height	134.2 mm
Weight	220 g
