For Reference: Charging with other power sources
NOTE: Charging with these power sources is not
guaranteed. Icom is not responsible for the destruction or
damage to charging with these power sources.
Charging time differs, depending on the power supply.
3
2
ACCESSORIES ATTACHMENTS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Charging with the supplied power adapter
Turn OFF the power. q
Connect the power adapter as shown below. w
•"CHG"isdisplayedandbarsinsideofthebatteryiconscroll
while charging.
•Whenerrorisdetected,thebatteryiconblinks,and"Er"and
"CHG"aredisplayed.
The charging is completed in approximately 3 hours. e
•Thechargingtimediffersdependingonthebatterycondition.
•"FL"isdisplayedwhenthebatteryhasbeenfullycharged.
IMPORTANT:
•ReadSection8(Pages22to24)beforecharging.
•Beforeusingthetransceiverforthersttime,fully
charge the battery for optimum life and operation.
•TurnOFFthepowerwhilechargingtoavoiddamageto
the battery.
Charging
Supplied
power adapter
[CHARGE] SOCKET
Power OFF
Slide the lock down.
Pull the cover down.
• PC’S USB port
A-Micro-B USB cable
(user supplied)
Some PCs may not supply
the required voltage and current.
Micro-B USB type charger*
External battery
Power adapter
Cigarette lighter socket
with power converter
*5 V, 1 A must be supplied.
PC’S USB port
A-Micro-B USB cable
(user supplied)
Some PCs may not supply
the required voltage and current.
• Micro-B USB type charger*
External battery
Power adapter
Cigarette lighter socket
with power converter
*5 V, 1 A must be supplied.

Table of Contents

Other manuals for Icom IC-M25

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Icom IC-M25 and is the answer not in the manual?

Icom IC-M25 Specifications

General IconGeneral
Battery typeBP-282
Battery life (max)11 h
Battery low indicationYes
Number of batteries supported1
PurposeMarine Radio Service
Operating frequency156.025 - 157.425 MHz
Display typeLCD
USB connector typeMicro-USB B
Antenna connector typeFA-SC59V
Product colorBlack, White
Waterproof up to1 m
International Protection (IP) codeIPX7
Operating temperature (T-T)-20 - 60 °C
Number of batteries included1 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth30.5 mm
Width56.6 mm
Height134.2 mm
Weight220 g
