Icom IC-M330 User Manual

59
SPECIFICATIONS AND OPTIONS
10
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
New2001
■ Options
• MBF-5 flush mount kit
To mount the transceiver to a panel.
• MA-500TR
class b ais transponder
To transmit individual DSC calls to a selected AIS targets.
D GPS Antenna
• Frequency : 1575.42 MHz
• Channel: 66 ch
• Deferential satellites: WAAS, EGNOS, MSAS, GAGAN
• GLONAS receiving frequency: 1602MHz
D Dimensions Unit: mm (inch)
66.5 (2.6)
25.8
(1)
84.3 (3.3)
62.4 (2.5)
137 (5.4)
51 (2)
156.5 (6.2)

Icom IC-M330 Specifications

General

Type	Marine VHF Transceiver
Output Power	25 W / 1 W
Waterproof Rating	IPX7
Display	LCD
Power Supply	13.8 V DC
Operating Temperature Range	-15°C to +55°C
Channels	USA, INT, CAN channels
Current Drain	5.5 A (at 25 W)
DSC	Yes, Class D
Modulation	16K0G3E
