BASIC OPERATION
3
D International channels
There are pre-programmed 57 international channels for the
IC-M505.
q Push [DIAL•DUAL/GRP] to select a regular channel.
w While pushing and holding [H/L], push [DIAL•DUAL/
GRP] to change the channel group, if necessary.
 •“INT” appears when International channel is selected.
e Rotate [CHANNEL] to select a channel.
 •“DUP” appears for duplex channels.
25W INT
DUP
TAG
34°34.506N
123°23.236W
UTC 12:00 PORT OPR
Push +
D U.S.A. channels (U.K. version only)
For U.K. version, there are pre-programmed 58 U.S.A. chan-
nels in addition to 57 International channels.
q Push [DIAL•DUAL/GRP] to select a regular channel.
w While pushing and holding [H/L], push [DIAL•DUAL/
GRP] to change the channel group, if necessary.
 •InternationalandU.S.A.channelscanbeselectedinsequence.
e Rotate [CHANNEL] to select a channel.
 •“DUP” appears for duplex channels.
25W USA
DUP
TAG
34°34.506N
123°23.236W
UTC 12:00 PORT OPR
Push +
D ATIS and DSC channels
(Holland and FRG versions only)
For Holland and FRG version, there are pre-programmed 57
ATIS and 57 DSC* channels in addition to 57 International
channels.
*FRG version only
q Push [DIAL•DUAL/GRP] to select a regular channel.
w While pushing and holding [H/L], push [DIAL•DUAL/
GRP] to change the channel group, if necessary.
 •International,ATISandDSCchannelscanbeselectedinse-
quence.
e Rotate [CHANNEL] to select a channel.
 •“DUP” appears for duplex channels.
25W DSC
TAG
34°34.506N
123°23.236W
UTC 12:00 CALLING
1W ATIS
TAG
COMMERCIAL
Push +
ATIS channel DSC channel
