Icom IC-M505

68
11
SPECIFICATIONS AND OPTIONS
D Dimensions
Unit: mm
110
108.4
165
145
31.4
91.4
77
123.2
■ Options
•MB-75 f l u s h m o u n t k i t
For mounting the transceiver to a panel.
•HM-162E
c o m m a n d m i c iii™
External microphone-type controller. Provides optional inter-
com operation. 6 m microphone cable and mount-ing base
included. Black and white colors are available.
•HM-126RB/RG
h a n d m i c r o p h o n e
Equipped with [Y]/[Z] (channel up/down,) [HI/LO] and
[PTT] keys, a speaker and microphone.
•OPC-1541
m i c r o p h o n e e x t e n s i o n c a b l e
6 m microphone extension cable for optional HM-162E c o m -
m a n d m i c iii™. Up to 2 OPC-1541 can be connected. (18 m;
maximum)
•OPC-1000
m i c r o p h o n e e x t e n s i o n c a b l e
6 m microphone extension cable for the supplied micro-
phone.
•OPC-1758
a n t e n n a f l o at i n g c a b l e
Connected between the transceiver and the antenna. Isolates
the transceiver from the the antenna ground, providing a
floating ground connection.
•UT-112
v o i c e s c r a m b l e r u n i t
Ensures private communications. 32 codes are available.
Not available in some countries.
