OPTIONAL SWIVEL BELT CLIP
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
■ Attaching
Screw the base clip to the q
back of the transceiver us-
ing the two screws
(sup-
plied), as shown to the right.
Clip the belt clip over your belt and insert the transceiver. w
Once the transceiver is locked in place, it swivels. e
■ Detaching
➥ Turn the transceiver upside down in the direction of the
arrow and pull out from the belt clip.
R CAUTION: HOLD THE TRANSCEIVER TIGHTLY WHEN
HANGING OR DETACHING THE TRANSCEIVER FROM
THE BELT CLIP.
Otherwise the transceiver may not be attached to the belt
clip or swivelled properly if the transceiver is accidentally
dropped and the base clip is scratched or damaged.
