PANEL DESCRIPTION
New2001 New2001
Controller — Display (Touch screen) (Continued) ■
D Function menu
You can toggle the function group to select the desired func-
tion keys to operate the transceiver, depending on the trans-
ceiver’s operating mode or status.
Each function key works for the MAIN band.
• In the VFO, Memory or Call channel mode, you can select
the F-1 to F-4 menus.
• In the DR screen, you can select the D-1 to D-3 menus.
Touch the group icon to toggle the function group. ➥
Touch the group icon for 1 second to display the function ➥
menu list.
q w e r t
q [V/M]
Touch to toggle between the VFO and Memory modes.
w [CALL]
Touch to turn the Call channel mode ON or OFF.
e [MW]
Touch to open the Memory Write window. ➥
In the VFO mode or the DR screen, touch for 1 second ➥
to store the operating data into the blank channel.
In the Memory or Call channel mode, touch for 1 sec- ➥
ond to open the Memory Edit screen.
r [SCAN]
Touch to open the Scan type setting window. ➥
Touch for 1 second to start the last used scan. ➥
t [MONI]
Touch to turn the Monitor function ON or OFF.
u i o !0y
y [SKIP]
(Appears in the Memory mode.)
Touch to open the Scan Skip setting window.
u [DTMF]
Touch to open the DTMF send window.
i [VOICE]
When you insert an SD card into the transceiver’s SD card
slot, touch to open the “VOICE TX” screen.
o [LOW]
Touch to open the TX power setting window.
!0 [GPS]
Touch to open the GPS item setting window.
To Next Page
