Icom ID-5100A

New2001New2001
11
New2001
BASICOPERATION
2
■ Power ON the power
Hold down [ ➥ ] for 1 second to turn ON the power.
• A beep sounds and, after the opening message and power source
voltage are displayed, the operating frequency appears.
• Hold down [ ] for 1 second to turn OFF the power.
■ Setting audio volume and
squelch level
Rotate [VOL] to adjust the audio level. q
Rotate [SQL] until the noise and the “BUSY” icon just dis- w
appear.
• Rotating [SQL] clockwise makes the squelch tight. The tight
squelch is for strong signals.
• When rotating [SQL] clockwise beyond the center position,
[SQL] can be used as ‘S-meter Squelch’ or ‘Attenuator.’ Select
the [SQL] option in the Menu screen. (p. 71)
■ Selecting a tuning step
Rotating [DIAL] changes the frequency in the selected tuning
steps.
The VFO scan uses this step to search for a signal.
Tuning steps (kHz)
5 6.25 8.33* 10 12.5 15
20 25 30 50 Auto*
*Appears only when the AIR band is selected.
D Tuning step selection
Touch the kHz digits for 1 second. q
• Opens the Tuning step setting window.
Touch the desired tuning step. w
• Sets the tuning step, and then returns to the previous screen.
• You can set the tuning step for both the VFO and Memory
mode.
• You can set the tuning step for each band.
• In the Tuning step setting window, rotating [DIAL] also selects
the tuning step.
[VOL] [VOL]
[SQL]
[SQL]
[ ]
To mute the audio, touch [QUICK] for 1 second. ➥
• Releases mute when rotating [DIAL], [VOL] or [SQL], or oper-
ating a key, touch screen or microphone.
