BEFORE USING REMOTE CONTROL SYSTEM
6
• When connecting to the network through a PC, the audio volume adjustment is needed for both the
Remote and Base station PCs.
• When connecting to the network directly, the audio volume adjustment is needed for only the Remote station PC.
Before you start using the RS-BA1, the PC’s audio volume must be set to a proper level.
When several audio devices are used, you must set each one individually.
• Congurable items, displayed screens and terms that are used may differ, depending on your PC.
When setting for the Base station PC
Adjust the audio volume input or output level from or to your radio.
In the “Playback devices” menu, you can adjust the modulation level sent to the radio.
In the “Recording devices” menu, you can adjust the audio input level from the radio.
Before adjusting, connect the radio and your PC, and turn ON the radio. (See page 16.)
When setting for the Remote station PC
Adjust the volume level of the audio device that is connected to the PC.
In the “Playback devices” menu, you can adjust the output level of the speaker or headset.
In the “Recording devices” menu, you can adjust the modulation level sent to the radio.
■ Volume adjustment for your audio devices
1. Right-click the speaker icon on the taskbar, then
click “Playback devices” or “Recording devices.”
2. The “Sound” screen appears, then click the
<Playback> tab.
In the list that appears, select the audio device
that you will use, then click <Properties>.
q Click
w Select
e Click
3. The “Speaker Properties” screen appears, then
conrm “Use this device (enable)” is displayed in
the Device Usage menu on the <General> tab.
q Click
w Confirm
4. Click the <Levels> tab.
Adjust the speaker’s audio level by moving the
slide control to the right or left.
• If the mute setting is turned ON in “Speakers” ( ),
click the icon to turn OFF.
q Right-click
w Click
Windows 10
☞ Continued on the next page.
