WHEN CONNECTING TO THE NETWORK THROUGH A PC
16
■ Connecting the radio to the Base station’s PC
Before connecting the radio to the PC, please nish the installation for the Base station's PC and the Remote
station's PC, using the RS-BA1 Preparations.
Check the connector type on your radio and see the following chart to connect your radio to the Base station’s
PC.
To connect an Icom CI-V command capable radio to the Base station’s PC, you have to make connections for
control command and audio communication.
RS-BA1 operation with the Base station’s PC connected to the radio’s ACC socket, MIC connector, or S/P DIF
jack for audio communication cannot be guaranteed.
Radio's connector
Outline
Model Ref.
Control command
Audio
When connecting
to the radio's [USB]
port
Through a USB cable
IC-7100/IC-7200/
IC-7300/IC-7410/
IC-7600
*1
/IC-
7610/IC-7850/IC-
7851/IC-9100
p. 17
When connecting
to the radio's
[REMOTE] jack
Through the
CT-17
ci-v level
converter
Through an audio cable connected
between the PC’s audio terminal
and the radio’s [ACC] socket or
[MIC] connector
All p. 18
When connecting
to the radio's [RS-
232C] port
Through an RS-
232C cable
Through an audio cable connected
between the PC’s audio terminal
and the radio’s [ACC] socket, [MIC]
connector or [S/P DIF] jack
IC-7700/IC-7800
*2
p. 19
D Select the connection pattern
*1 When you turn your radio ON or OFF from the Remote Controller, connect to the radio's [Remote] jack.
*2 When you turn your radio ON or OFF from the Remote Controller, connect to the radio's [Remote] jack or to
the network directly.
