WHEN CONNECTING TO THE NETWORK THROUGH A PC
21
■ Radio’s presetting
The RS-BA1 remotely controls Icom radios using CI-V (Icom Communication Interface) commands. See the CI-V
command table in the radio’s instruction manual for details of the functions that can be controlled.
D The following manual settings are required when operating the RS-BA1
Properly preset the items in below table for functions that cannot be controlled by CI-V commands or the item
may cause unwanted actions. See the radio’s instruction manual for details of the settings or operation.
NOTE:
• Remove the transverter from the radio, if it is connected.
• To prevent an accidental transmission, we recommend you remove any keyer, keypad or other external
equipment connected to the radio.
• Set the radio to a normal operating mode. The radio cannot receive CI-V commands while in special modes,
such as the rmware update mode or cloning mode.
• If the radio has a Time-Out Timer function, we recommend you enable it to prevent the radio from continuously
transmitting.
Genre Item Model Setting
Function
RIT function All Set to OFF.
∂TX function All Set to OFF.
Simple band scope IC-746PRO*/IC-7000*/IC-7100/
IC-7400*/IC-9100
Set to OFF.
SWR Measurement function IC-746PRO*/IC-7000*/IC-7100/
IC-7400*/IC-9100
Set to OFF.
Timer/Sleep Timer function Radios with the timer function Set the timer to OFF or to your
schedule.
Weather Alert function IC-7100 Set to OFF.
Display
RTTY decode screen IC-746PRO*/IC-756PROIII*/IC-7400* Exit the screen.
Volume
Volume for the RX audio All Set the volume to a suitable level.
CI-V
CI-V address All Set an appropriate CI-V address.
CI-V baud rate All Set to 19200 bps (or Auto).
CI-V USB Port IC-7300/IC-7610/
IC-7850 (Firmware version 1.10 or later)/
IC-7851 (Firmware version 1.10 or later)
To use the Scope function when
connecting to the USB port, set to
Unlink from [REMOTE].
CI-V USB Baud Rate IC-7300/IC-7610/
IC-7850 (Firmware version 1.10 or later)/
IC-7851 (Firmware version 1.10 or later)
To use the Scope function when
connecting to the USB port, set to
115200 (or Auto).
Set mode
USB Serial Function Radios with a USB (B type) port Set to “CI-V” for the selected
connection type.
RS-232C Function Radios with an RS-232C port Set to “CI-V” for the selected
connection type.
* Operation on models without a USB connection cannot be guaranteed.
If you are using the IC-PW1 with the transceiver, be sure to set the CI-V baud rate to 19200 bps. After changing
the transceiver’s CI-V settings, be sure to reset the CPU of the IC-PW1 and set the transceiver’s CI-V settings
on the IC-PW1. See the IC-PW1 instruction manual for details.
