INSTALLATION
Ideal Logic Code Combi - Installation and Servicing

FLUE KITS
Pack B - supplied as standard
Pack B - optional telescopic
Pack D
Concentric Flue Retaining Kit - 

Finishing Kit 
Refer to ‘Flue Extension Ducts’
IMPORTANT.  be installed in a vertical position
Dimension X  
Dimension L  
Dimension S  
10 DETERMINING THE FLUE LENGTH AND FLUE PACKS REQUIRED
Note. MAXIMUM FLUE LENGTHS:
26 - 9M (HORIZONTAL FLUE)
33 - 8M (HORIZONTAL FLUE)
38 - 6M (HORIZONTAL FLUE)
26, 33, 38 - 7.5M (ROOF FLUE)
26, 33, 38 - 5M PRIMARY AND 17M SECONDARY IS A TYPICAL MAX.
FLUE LENGTH. (
90
O

45
O

 
(C 
197mm
197mm
Wall Thickness X
Side flue length L
155 mm
155 + S = 200mm
206279-10256
SIDE FLUE
REAR FLUE
197mm
197mm
Wall Thickness X
Side flue length L
155 mm
155 + S = 200mm
206279-10256
continued . . . . .
