The communication cartridges can only be used when connected to cartridge slots 1 and 2 of the CPU module.
This port can be used to communicate with RS232C/RS485 communication-compatible external devices such as computers,
operator interfaces, and printers. Maintenance communication, user communication, Modbus RTU communication (master/slave),
and data link communication (master station/slave station) are possible.
CAN Port
The CAN J1939 All-in-One Type can use this port to perform J1939 communication.
HMI-Ethernet Port
The HMI-Ethernet port can only be used when a CPU module and an HMI module are connected.
This port can be used to communicate with Ethernet communication-compatible external devices such as computers and operator
interfaces.
This port has eight connections that can be used with Ethernet communication. Each connection can be configured for
maintenance communication (server).
This port also supports the web server function and the send E-mail function.
Type No. FC6A-PC1 FC6A-PC3
Electrical Characteristics EIA RS232C EIA RS485
Maximum Communication Speed 115,200 bps 115,200 bps
Communication Functions Maintenance communication, user communication, Modbus communication, data link communication
Maximum Cable Length 5 m 200 m
Isolation between Internal Circuit Not isolated Not isolated
Cable
Recommended
Cable
Shielded multicore: 24 AWG Shielded twisted-pair: 24 AWG
Communication Type CAN bus communication
Communication Speed 250 kbps
Communication Functions J1939 communication
Connector FC6A-PMTE05PN02
Cable
SAE-J1939-11 : Shielded twisted-pair
SAE-J1939-15 : Unshielded twisted-pair
Maximum Cable Length
SAE-J1939-11 : 40 m, stub 1 m maximum
SAE-J1939-15 : 40 m, stub 3 m maximum
Terminating Resistance 120 Ω (0.5 W or higher)
Isolation between Internal Circuit
Power supply: Transformer isolated
Signal: Galvanic isolation, photocoupler isolated
Communication Type IEEE 802.3 compliant
Communication Speed 10BASE-T, 100BASE-TX
Number of Connections 8 maximum
Communication Mode Maintenance Communication
Web Server Function Yes
Web Data Storage FROM
Web Data
Capacity
System Web Page Used Used Not used Not used
Web Page Editor Used Not used Used Not used
Area Available to User 2.5 MB 4.5 MB 3.0 MB 5.0 MB
Send E-mail Function Yes
Connector RJ45
Cable CAT 5. STP or higher
Maximum Cable Length 100 m
Isolation between Internal Circuit Pulse transformer isolated
• When accessing the FC6A Series MicroSmart over the Internet, adequate security measures for the network to prevent
unauthorized access are required. Be sure to consult your network administrator or Internet service provider. IDEC bears
no responsibility for damages or problems caused due to security in Ethernet communication.
• Restrict the access to FC6A Series MicroSmart with IP addresses and ports by using appropriate measures such as the
firewall.
Caution
