10: S
END
E-
MAIL
F
UNCTION
10-8 FC6A S
ERIES
M
ICRO
S
MART
A
LL
-
IN
-O
NE
T
YPE
C
OMMUNICATION
M
ANUAL
FC9Y-B1730
E-mail Address Book
The e-mail addresses and e-mail address groups can be configured in E-mail Address Book dialog box. E-mail addresses can be
grouped into an e-mail address group. The e-mail address group can be used to specify a group of e-mail addresses in each
e-mail.
Programming WindLDR
1. Double-click on the E-mail Address Book in the Project Window.
The E-mail Address Book dialog box appears.
2. Click the ▼ next to the New E-mail Address, and then click New E-mail Address. Alternatively, select an existing E-mail
address, and then click the Edit button.
The E-mail Address dialog box appears.
3. Configure the settings.
(1) Direct
Specify the e-mail address to register in the E-mail Address Book dialog box. A maximum of 40 ASCII characters can be entered.
(2) Data Register
Specify the data register to store the e-mail address. When sending an e-mail, the string stored in a maximum of 30 words of
data registers starting from the specified data register is used as e-mail address for the E-mail recipients (To and CC). When
specifying an e-mail address with a string using data registers, the length of the e-mail address is considered as 60 bytes fixed.
When specifying all e-mail addresses with data registers, a maximum of eight e-mail addresses can be set for the E-mail
recipients (To and CC).
(3) Comment
The comment for the e-mail address can be assigned. The contents or the length of the comment has no effect on the CPU
module operation.
To Next Page
