FC6A S
ERIES
M
ICRO
S
MART
A
LL
-
IN
-O
NE
T
YPE
C
OMMUNICATION
M
ANUAL
FC9Y-B1730 1-1
1: GENERAL INFORMATION
Introduction
This chapter describes an overview of the FC6A Series MicroSmart, which is equipped with a communication interface.
Description
The FC6A Series MicroSmart can perform RS232C and RS485 communication using serial port 1. The communication ports can be
expanded by using communication cartridges to allow for multiple instances of RS232C and RS485 communication. The Ethernet
port is standard equipment to enable communication using Ethernet. Also, the Ethernet port can be expanded by using an HMI
module. The CAN J1939 All-in-One Type is equipped with a CAN port to enable J1939 communication.
Communication Interfaces
An overview and the specifications of the communication interfaces are shown below.
USB Port
Maintenance communication can be performed by using this port to connect to a computer.
Serial Port 1
This port can be used to communicate with RS232C/RS485 communication-compatible external devices such as computers,
operator interfaces, and printers.
Maintenance communication, user communication, Modbus RTU communication (master/slave), and data link communication
(master station/slave station) are possible.
Ethernet Port 1
This port can be used to communicate with Ethernet communication-compatible external devices such as computers and operator
interfaces.
This port has eight connections that can be used with Ethernet communication. Each of these connections can simultaneously use
a different communication protocol. Each connection can be configured for maintenance communication (server), user
communication (server/client), or Modbus TCP communication (server/client).
Communication Type USB2.0 Full speed, CDC class
Communication Functions Capable of maintenance communication with a PC, program downloads via USB power
Connector USB mini-B
Isolation between Internal Circuit Not isolated
Communication Type EIA RS-232C or RS-485 software selectable
Maximum Communication Speed 115,200 bps
Communication Functions
Maintenance communication, user communication, Modbus RTU communication, data link
communication
Connector RJ45
Cable
RS232C: Shielded multicore
RS485: Shielded twisted-pair
Maximum Cable Length
RS-232C: 5 m
RS-485 : 200 m
Isolation between Internal Circuit Not isolated
Communication Type IEEE 802.3 compliant
Communication Speed 10BASE-T, 100BASE-TX
Number of Connections 8 maximum
Communication Functions Maintenance communication, user communication, Modbus TCP server/client
Connector RJ45
Cable CAT 5. STP
Maximum Cable Length 100 m
Isolation between Internal Circuit Pulse transformer isolated
