FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE C OMMUNICATION M ANUAL FC9Y-B1730 2-1
2: DEVICE
This chapter provides detailed descriptions of the allocations of devices such as inputs, outputs, internal relays, registers, timers,
and counters that are used in the basic and advanced instructions, as well as details about the allocations of special internal relays
and special data registers.
Please use this chapter as a reference when entering and editing devices in the user program.
Note: The entry and operation of FC6A Series MicroSmart user programs requires specialist knowledge.
Take the time to develop a thorough understanding of the contents and programs in this manual before using the FC6A Series MicroSmart.
Device Addresses
*1 The least significant digit of the device address is an octal number (0 to 7).
*2 I190 to I507 and Q190 to Q507 are devices that can only be used when an expansion module (expansion interface side) is connected using the
expansion interface module.
*3 I310 to I627 and Q310 to Q627 are devices that can only be used when an expansion module (expansion interface side) is connected using the
expansion interface module.
Device Symbol Unit
Range (Points)
16-I/O Type 24-I/O Type 40-I/O Type
Inputs
*1
IBit
I0 - I10
(9 points)
I0 - I15
(14 points)
I0 - I27
(24 points)
Expansion Input Relays
*1
IBit
I30 - I187
(128 points)
I190 - I507
*2
(256 points)
I30 - I307
(224 points)
I310 - I627
*3
(256 points)
Output
*1
QBit
Q0 - Q6
(7 points)
Q0 - Q11
(10 points)
Q0 - Q17
(16 points)
Expansion Outputs
*1*3
QBit
Q30 - Q187
(128 points)
I190 - I507
*2
(256 points)
Q30 - Q307
(224 points)
Q310 - Q627
*3
(256 points)
Internal Relay
*1
MBit
M0 - M7997
(6,400 points)
M10000 - M17497
(6,000 points)
Special Internal Relay
*1
MBit
M8000 - M8317
(256 points)
Shift Register R Bit
R0 - R255
(256 points)
Timer T Bit/Word
T0 - T1023
(1,024 points)
Counter C Bit/Word
C0 - C511
(512 points)
Data Register D Bit/Word
D0000 - D7999
(8,000 points)
D10000 to D55999
(46,000 points)
Special Data Register D Bit/Word
D8000 - D8499
(500 points)
