FC6A S
ERIES
M
ICRO
S
MART
A
LL
-
IN
-O
NE
T
YPE
C
OMMUNICATION
M
ANUAL
FC9Y-B1730 11-1
11: WEB SERVER
Introduction
This chapter describes the Web server functions in the FC6A Series MicroSmart.
Overview
The HMI-Ethernet port of the HMI module supports the Web server functions.The Web server enables you to access the FC6A
Series MicroSmart using web browser on your PC in order to monitor the status or change the device data. Users can also
download web page data that was freely created and build easy-to-use web sites for each project.
On the system web page, the PLC status can be monitored and data register values can be changed. The FC6A Series MicroSmart
provides CGI so that you can access data register values of the FC6A Series MicroSmart from a web browser using JavaScript. The
system library is also provided so that you can show data register values on your web page using system library parts, such as
numerical input, bar graph, or trend graph, without special knowledge of JavaScript.
The Web server is protected with basic authentication. Access from people who do not have user name and password can be
prevented.
The tree structure of web page
The tree of structure of the web page of web server in the FC6A Series MicroSmart is shown below:
The imported files or folders in the Project Window of WindLDR are added under the root folder of the web page. If the IP address
of the FC6A Series MicroSmart is 192.168.1.5, enter the following URL on the web browser to access the top page of the system
web page.
http://192.168.1.5/system/index.html
When a folder is specified as URL, index.html in the folder is displayed. For example, the following URL opens the same page with
the above URL.
http://192.168.1.5/system/
/index.html:
/system/:
/system/index.html:
/user/:
System top page. Automatically generated by WindLDR.
The root folder of the system web page. Automatically generated by WindLDR.
The top page of the system web page.
User web page folder.
