10: S
END
E-
MAIL
F
UNCTION
10-10 FC6A S
ERIES
M
ICRO
S
MART
A
LL
-
IN
-O
NE
T
YPE
C
OMMUNICATION
M
ANUAL
FC9Y-B1730
E-mail Editor
The e-mails can be configured in E-mail Editor dialog box. The following five parameters should be configured for each e-mail.
Settings in E-mail Editor
(1) E-mail recipients (To and Cc)
E-mail address or e-mail group can be specified as the recipients. The maximum size of texts for To or Cc is 512 bytes. Comma
(,) is inserted as a separating character between e-mail addresses. For example, the total size of an e-mail group "ccc"
containing two e-mail addresses "aa@example.com" (15 bytes including a comma) and "bbb@example.com" (16 bytes including
a comma) is 31 bytes. If the size of e-mail addresses is 30 bytes, 16 e-mail addresses can be specified in To and CC
respectively. An e-mail can be sent to 32 e-mail addresses simultaneously.
(2) E-mail subject and body
The maximum size of texts is 256 bytes for Subject and 4,096 bytes for e-mail body. The e-mail subject and body are
composed from the following elements.
• Strings that use character set under E-mail Settings in the Function Area settings
• Numeric value strings of the values of data registers that have been embedded in the body by inserting data registers
• Spaces and newlines
The size of the e-mail subject and body is the text that is composed of the combination of the above elements.
The result of encoding the composed text according to Text encoding under E-mail Settings in the Function Area settings
is sent as the e-mail.
When only single-byte ASCII characters are used, approximately 200 characters can be entered for e-mail subject and 3,500
characters for e-mail body. When multi-byte characters are used, approximately 100 characters can be entered for e-mail
subject and 2,000 characters for e-mail body
(3) Attached file
One CSV file can be attached to an e-mail. The attached file can include text and data register values. The file name of the CSV
file is fixed as "data.csv". The maximum size of the attached file is 4,096 bytes.
The attached file composed from the following elements.
• Strings that use character set under E-mail settings in the Function Area settings
• Numeric value strings of the values of data registers that have been embedded in the body by inserting data registers
• Spaces, separator characters, and newlines
The size of the attached file is the text that is composed of the combination of the above elements.
The result of encoding the composed text according to Text encoding under E-mail Settings in the Function Area settings
is attached to the e-mail.
