4: M AINTENANCE C OMMUNICATION
4-2 FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE C OMMUNICATION M ANUAL FC9Y-B1730
Maintenance communication functions that are supported by the communication ports and slots are as follows.
Communication
Port
Standard/Option No. of Ports Communication Settings
USB Port Standard 1 None
Port 1
All-in-One Type: Standard equipment
CAN J1939 All-in-One Type: ―
1
Function area settings
See "Maintenance Communication via Port 1"
on page 4-4.
Ethernet Port 1 Standard 1
Function area settings
See "Maintenance Communication via Ethernet
Port 1" on page 4-6.
Port 2 and Port 3
Options
FC6A-PC1: EIA RS-232C (terminal block)
FC6A-PC3: EIA RS-485 (terminal block)
16-I/O type: 1
24-I/O type: 1
40-I/O type: 2
Function area settings
See "Maintenance Communication via a
Communication Cartridge (Port 2, Port 3)" on
page 4-11.
HMI-Ethernet Port
Options
FC6A-PH1 (HMI module)
1
Function area settings
See "Maintenance Communication via HMI-
Ethernet port" on page 4-13
