IDEC MICROSmart FC6A Series User Manual

2: P RODUCT S PECIFICATIONS
2-108 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Function Specifications
■ Analog Input Specifications
Analog Input Module
Type No.
FC6A-J2C1
FC6A-J2C4
FC6A-J4A1
FC6A-J4A4
FC6A-J8A1
FC6A-J8A4
FC6A-J4CN1
FC6A-J4CN4
FC6A-J4CH1Y
FC6A-J4CH4Y
FC6A-J8CU1
FC6A-J8CU4
Input Type
and Input
Range
Voltage
0 to 10 V
-10 to 10 V
―
Current
4 to 20 mA
0 to 20 mA
―
Thermocouple ―
(K) -200 to 1,300°C (-328 to 2,372°F)
(J) -200 to 1,000°C (-328 to 1,832°F)
(R) 0 to 1,760°C (32 to 3,200°F)
(S) 0 to 1,760°C (32 to 3,200°F)
(B) 0 to 1,820°C (32 to 3,308°F)
(E) -200 to 800°C (-328 to 1,472°F)
(T) -200 to 400°C (-328 to 752°F)
(N) -200 to 1,300°C (-328 to 2,372°F)
(C) 0 to 2,315°C (32 to 4,199°F)
Resistance
Thermometer
*1
―
Pt100:
-200 to 850°C
(-328 to
1,562°F)
Pt1000:
-200 to +600°C
(-328 to
1,112°F)
Ni100:
-60 to +180°C
(-76 to 356°F)
Ni1000:
-60 to +180°C
(-76 to 356°F)
―
Thermistor ―
NTC
(-90 to 150°C)
PTC
(100 to 10,000 Ω)
Resistor ― 100 to 32,000 Ω
Input
Impedance
Voltage 1 MΩ or higher
Current 50 Ω or lower
Thermocouple 1 MΩ or higher
Resistance Thermometer 1 MΩ or higher
Thermistor 1 MΩ or higher
Resistor 1 MΩ or higher
AD
Conversion
Sampling Time 1 ms 1 ms or 10 ms
10 ms, 100 ms
or 104 ms
120 ms or 30
ms
104 ms
Sampling Repetition Time Sampling time × Number of enabled input channels
Total Input Delay Time
*2
Sampling time + Sampling repetition time + 1 scan time
Type of Input Single-ended
Differential
input
Single-ended
Operation Mode Self-scan
Conversion Method Σ∆ type ADC
Input Error
Maximum Error at 25°C
±0.1% of full
scale
±0.2% of full scale
±0.2% of full scale
Cold junction compensation accuracy: ±4.0°C or
lower
Exceptions
R, S: ±6°C (0 to 200°C)
B: Not possible to guarantee accuracy (0 to 300°C)
K, J, E, T, N:
±0.4% of full scale (0°C or lower)
Temperature Coefficient 0.006%/°C 0.01%/°C
