FC6A S
ERIES
MICROS
MART
U
SER
’
S
M
ANUAL
FC9Y-B1722 2-109
2: P
RODUCT
S
PECIFICATIONS
Data
Digital
Resolution
Voltage
65,536
(16 bits)
4,096
(12 bits)
65,536
(16 bits)
*3
65,536 (16 bits) ―
Current
65,536
(16 bits)
4,096
(12 bits)
65,536
(16 bits)
*3
65,536 (16 bits) ―
Thermocouple
―
K: 15,000 (14 bits)
J: 12,000 (14 bits)
R: 17,600 (15 bits)
S: 17,600 (15 bits)
B: 18,200 (15 bits)
E: 10,000 (14 bits)
T: 6,000 (13 bits)
N: 15,000 (14 bits)
C: 23,150 (15 bits)
Resistance
Thermometer
―
Pt100:
10,500 (14 bits)
Pt1000:
8,000 (13 bits)
Ni100:
2,400 (12 bits)
Ni1000:
2,400 (12 bits)
―
Thermistor ―
NTC: 2,400 (12 bit)
PTC: 9,900 (14 bit)
Resistor ― 31,900 (15 bit)
Input
Value per
Step
Voltage
0.15 mV
(0 to 10 V)
0.30 mV
(-10 to +10 V)
2.44 mV
(0 to 10 V)
4.88 mV
(-10 to +10 V)
0.15 mV
(0 to 10 V)
*3
0.30 mV
(-10 to +10 V)
*3
0.15 mV
(0 to 10 V)
0.30 mV
(-10 to +10 V)
―
Current
0.30 μA
(0 to 20 mA)
0.244 μA
(4 to 20 mA)
4.88 μA
(0 to 20 mA)
3.91 μA
(4 to 20 mA)
0.30 μA
(0 to 20 mA)
*3
0.244 μA
(4 to 20 mA)
*3
0.30 μA
(0 to 20 mA)
0.244 μA
(4 to 20 mA)
―
Thermocouple
― 0.1°C or 0.18°F
Resistance
Thermometer
Thermistor
(NTC)
Thermistor
(PTC)
― 1 Ω
Data Type in Application
Program
Can be arbitrarily set for each CH in a range between -32,768 to 32,767
*4
Monotonicity Yes
Input Data Out of Range Detectable
*5
Noise
Resistance
Maximum Temporary
Deviation during
Electrical Noise Tests
±4.0% or lower
Input Filter Yes
Recommended Cable
for Noise Immunity
Current/voltage: Pair shielded cable
Other: Pair cable
Crosstalk 1 LSB or lower
Isolation
Between Input and Power
Circuit
Isolated power supply
Between Input and
Internal Circuit
Photocoupler isolated
Between Inputs ―
Photocoupler
isolated
―
Effect of Improper Input Connection No damage
Type No.
FC6A-J2C1
FC6A-J2C4
FC6A-J4A1
FC6A-J4A4
FC6A-J8A1
FC6A-J8A4
FC6A-J4CN1
FC6A-J4CN4
FC6A-J4CH1Y
FC6A-J4CH4Y
FC6A-J8CU1
FC6A-J8CU4
