2: P RODUCT S PECIFICATIONS
2-122 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
■ FC6A-K2A1, FC6A-K2A4
For wiring precautions, see "Input/Output Wiring" on page 3-18.
*1 24V DC for products with a version number lower than V400. For details on the version number of modules, see "Checking the Version Number"
on page 2-1.
Screw fastened type: FC6A-K2A1 Push-in type: FC6A-K2A4
Applicable connector: FC6A-PMTB11PN02 Applicable connector: FC6A-PMSB11PN02
PWR
ANALOG
FC6A-K2A1
Q0- Q0+ 0V
24V
NC NC Q1- Q1+ NC NC
PWR
ANALOG
FC6A-K2A4
Q0- Q0+ 0V
24V
NC NC Q1- Q1+ NC NC
: Fuse
0V
24V
Terminal No. I/O
FE
Q0+
Q0-
12/24V
DC
*1
OUT0
Q1+
Q1-
OUT1
NC
NC
NC
NC
NC
NC
NC
NC
+
-
Analog Voltage/
current Input Device
+
-
Analog Voltage/
current Input Device
- +
