FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-123
2: P RODUCT S PECIFICATIONS
■ FC6A-K4A1, FC6A-K4A4
For wiring precautions, see "Input/Output Wiring" on page 3-18.
Screw fastened type: FC6A-K4A1 Push-in type: FC6A-K4A4
Applicable connector: FC6A-PMTB11PN02 Applicable connector: FC6A-PMSB11PN02
PWR
ANALOG
FC6A-K4A1
Q3- Q3+ Q2- Q2+ Q1- Q1+ Q0- Q0+ 0V
24V
PWR
ANALOG
FC6A-K4A4
Q3- Q3+ Q2- Q2+ Q1- Q1+ Q0- Q0+ 0V
24V
: Fuse
0V
24V
FE
Q0+
Q0-
24V DC
OUT0
Q1+
Q1-
OUT1
Q2+
Q2-
OUT2
Q3+
Q3-
OUT3
Terminal No. I/O
+
-
+
-
Analog Voltage/
current Input Device
+
-
Analog Voltage/
current Input Device
+
-
Analog Voltage/
current Input Device
- +
Analog Voltage/
current Input Device
