FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-129
2: P RODUCT S PECIFICATIONS
Quantity of Applicable PID Modules
The maximum number of PID modules that can be connected depends on the CPU module type. The maximum number of PID
modules that can be connected to the CPU modules is as follows.
*1 When the expansion interface module (expander) is used, an additional eight PID modules can be connected to the expansion interface side
(right side) of the expansion interface module (expander). The maximum number of modules that can be connected does not include the
expansion interface module (expander).
*2 The number of modules that can be connected does not include the expansion interface modules (expander and remote master/slave).
Module Type Type No. Quantity of Applicable PID Modules
All-in-One CPU module
All-in-One CPU
module
FC6A-C16R1AE, FC6A-C16R4AE
FC6A-C16R1CE, FC6A-C16R4CE
FC6A-C16K1CE, FC6A-C16K4CE
FC6A-C16P1CE, FC6A-C16P4CE
FC6A-C16R1DE, FC6A-C16R4DE
FC6A-C16K1DE, FC6A-C16K4DE
FC6A-C16P1DE, FC6A-C16P4DE
4 modules + 8 modules
*1
FC6A-C24R1AE, FC6A-C24R4AE
FC6A-C24R1CE, FC6A-C24R4CE
FC6A-C24K1CE, FC6A-C24K4CE
FC6A-C24P1CE, FC6A-C24P4CE
7 modules + 8 modules
*1
FC6A-C40R1AE, FC6A-C40R4AE
FC6A-C40R1CE, FC6A-C40R4CE
FC6A-C40K1CE, FC6A-C40K4CE
FC6A-C40P1CE, FC6A-C40P4CE
FC6A-C40R1DE, FC6A-C40R4DE
FC6A-C40K1DE, FC6A-C40K4DE
FC6A-C40P1DE, FC6A-C40P4DE
CAN J1939 All-in-One
CPU module
FC6A-C40R1AEJ, FC6A-C40R4AEJ
FC6A-C40R1CEJ, FC6A-C40R4CEJ
FC6A-C40K1CEJ, FC6A-C40K4CEJ
FC6A-C40P1CEJ, FC6A-C40P4CEJ
FC6A-C40R1DEJ, FC6A-C40R4DEJ
FC6A-C40K1DEJ, FC6A-C40K4DEJ
FC6A-C40P1DEJ, FC6A-C40P4DEJ
Plus CPU module
Plus CPU module
FC6A-D16R1CEE
FC6A-D16R4CEE
FC6A-D16K1CEE
FC6A-D16K4CEE
FC6A-D16P1CEE
FC6A-D16P4CEE
63 modules
*2
FC6A-D32K3CEE
FC6A-D32K4CEE
FC6A-D32P3CEE
FC6A-D32P4CEE
