Power Supply Specifications
Function Specifications
■ Input Specifications
Type No. FC6A-F2M1, FC6A-F2M4 FC6A-F2MR1, FC6A-F2MR4
External Power
Power Supply Voltage 24V DC
Allowed Fluctuation
Range
20.4 to 28.8V DC
Terminal Arrangement See "Terminal Arrangement and Wiring Examples" on page 2-135
Connector
Insertion/Removal
Durability
100 times minimum
Module 5V DC 65 mA 65 mA
Internal
Current Draw
24V DC 0 mA 0 mA
Module External Power Supply Current
Draw
150 mA (24V DC) 150 mA (24V DC)
Weight (approx.)
FC6A-F2M1: 140 g
FC6A-F2M4: 130 g
FC6A-F2MR1: 140 g
FC6A-F2MR4: 130 g
Type No. FC6A-F2M1, FC6A-F2M4, FC6A-F2MR1, FC6A-F2MR4
Input Type
and
Input Range
Voltage
0 to 10 V
0 to 5 V
1 to 5 V
0 to 1 V
Current
4 to 20 mA
0 to 20 mA
Thermocouple
K -200 to 1,370°C -328 to 2,498°F
K (with decimal point) -200.0 to 400.0°C -328.0 to 752.0°F
J -200 to 1,000°C -328 to 1,832°F
R 0 to 1,760°C 32 to 3,200°F
S 0 to 1,760°C 32 to 3.200°F
B 0 to 1,820°C 32 to 3,308°F
E -200 to 800°C -328 to 1,472°F
T -200.0 to 400.0°C -328.0 to 752.0°F
N -200 to 1,300°C -328 to 2,372°F
PL-II 0 to 1,390°C 32 to 2,534°F
C (W/Re5-26) 0 to 2,315°C 32 to 4,199°F
Resistance Thermometer
*1
Pt100 -200 to 850°C -328 to 1,562°F
Pt100 (with decimal
point)
-200.0 to 850.0°C -328.0 to 1,562.0°F
JPt100 -200 to 500°C -328 to 932°F
JPt100 (with decimal
point)
-200.0 to 500.0°C -328.0 to 932.0°F
Input
Impedance
Voltage
1 MΩ or higher (0 to 1 V range)
100 kΩ or higher (other range)
Current 50 Ω or lower
Thermocouple 1 MΩ or higher
Resistance Thermometer 1 MΩ or higher
AD Conversion
Sampling Time 100 ms
Sampling Repetition Time 100 ms
Total Input Delay Time
*2
Sampling time + Sampling repetition time + 1 scan time
Type of Input Differential input
Operation Mode Self-scan
Conversion Method Σ∆ type ADC
