FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-131
2: P RODUCT S PECIFICATIONS
Input Error
Maximum Error at
25°C
Thermocouple
Within ±0.2% of full scale or ±2°C (4°F), whichever is larger
Cold junction compensation accuracy: ±1.0°C or lower
However, R, S input 0 to 200°C (0 to 400°F) is within ±6°C (12°F)
B input 0 to 300°C (0 to 600°F) is outside the guaranteed range of
accuracy
K, J, E, T, N input less than 0°C (32°F) is within ±0.4% of full scale
Resistance
Thermometer
Within ±0.1% of full scale or ±1°C (2°F), whichever is larger
Voltage/
Current
Within ±0.2% of full scale
Temperature Coefficient ±0.005% of full scale/°C
Data
Digital Resolution
Voltage 12,000 (14 bits)
Current 12,000 (14 bits)
Thermocouple
Celsius (°C) Fahrenheit (°F)
K 1,570 2,826
K (with decimal point) 6,000 10,800
J 1,200 2,160
R 1,760 3,169
S 1,760 3,169
B 1,820 3,277
E 1,000 1,800
T 6,000 10,800
N 1,500 2,700
PL-II 1,390 2,503
C (W/Re5-26) 2,315 4,168
Resistance
Thermometer
*1
Celsius (°C) Fahrenheit (°F)
Pt100 1,050 1,890
Pt100 (with decimal
point)
10,500 18,900
JPt100 700 1,260
JPt100 (with decimal
point)
7,000 12,600
Input Value per
Step
Voltage
0 to +10V DC: 0.83 mV
0 to +5V DC: 0.416 mV
1 to +5V DC: 0.333 mV
0 to +1V DC: 0.083 mV
Current
4 to 20mA DC: 1.333 μA
0 to 20mA DC: 1.666 μA
Thermocouple
Type Input Value per Step
K1°C (°F)
K (with decimal point) 0.1°C (°F)
J1°C (°F)
R1°C (°F)
S1°C (°F)
B1°C (°F)
E1°C (°F)
T0.1°C (°F)
N1°C (°F)
PL-II 1°C (°F)
C (W/Re5-26) 1°C (°F)
Type No. FC6A-F2M1, FC6A-F2M4, FC6A-F2MR1, FC6A-F2MR4
