FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-167
2: P RODUCT S PECIFICATIONS
Wiring Arrangement and Wiring Examples
Insert a fuse that corresponds to the load.
FC6A-PN4
DC. IN
0
3
12 COM COM
FC6A-PTK4
Tr.OUT SINK
0
3
12
V+
FC6A-PTS4
Tr.OUT SOURCE
0312 COM(+)COM(-) V-
:Fuse
:Load
PNP
2-wire Sensor
2-wire Sensor
10.2 to 28.8V DC 10.2 to 28.8V DC
NPN
10.2 to 28.8V DC
10.2 to 28.8V DC
Rated Load: 12 to 24V DC/0.1 A
FC6A-PN4
FC6A-PTK4 FC6A-PTS4
