2: P
RODUCT
S
PECIFICATIONS
2-174 FC6A S
ERIES
MICROS
MART
U
SER
’
S
M
ANUAL
FC9Y-B1722
Function Specifications
■ Communication Specifications
Type No. FC6A-PC1 FC6A-PC3
Rated Power Voltage 5.0 V, 3.3 V (supplied from module) 5.0 V, 3.3 V (supplied from module)
Current Draw
5.0 V: Max 23 mA
3.3 V: Max 6 mA
5.0 V: Max 23 mA
3.3 V: Max 6 mA
Weight 15 g 15 g
Type No. FC6A-PC1 FC6A-PC3
Electrical Characteristics EIA RS232C EIA RS485
Maximum Communication Speed 115,200 bps 115,200 bps
Maintenance Communication Yes Yes
User Communication Yes Yes
Data Link Communication Yes Yes
Modbus Master Yes Yes
Modbus Slave Yes Yes
Maximum Cable Length 5 m 200 m
Isolation between Internal Circuit Not isolated Not isolated
Cable Recommended Cable Shielded multicore cable: 24 AWG Shielded twisted-pair cable: 24 AWG
When connecting cables to the communication cartridges, the tightening torque is 0.22 to 0.25 Nm.
Recommended screwdriver: SZS 0.4×2.5 (Phoenix Contact) and SDS 0.4×2.5×75 (Weidmüller)
Caution
To Next Page
