FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-181
2: P RODUCT S PECIFICATIONS
*1 9.3 mm when the hook is pulled out.
*1 9.3 mm when the hook is pulled out.
Digital input modules: FC6A-N16B3
Digital output modules: FC6A-T16K3, FC6A-T16P3
Digital input modules: FC6A-N32B3
Digital output modules: FC6A-T32K3, FC6A-T32P3
5.0
90.0
17.63.8
73.0
10.1
4.0
*1
All dimensions in mm.
5.0
30.2
3.8
90.0
10.1
73.0
4.0
*1
All dimensions in mm.
