7: HMI F UNCTION
7-22 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Changing the HMI module network settings
■ Changing the setting
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select Configurations with the (up) and (down) buttons and press the (OK) button.
3. Select Function with the (up) and (down) buttons and press the (OK) button.
4. Select Communications with the (up) and (down) buttons and press the (OK) button.
5. Select HMI Network Settings with the (up) and (down) buttons and press the (OK) button.
6. Select Setting with the (up) and (down) buttons and press the (OK) button.
7. With the (up) and (down) buttons, select ON or OFF.
Notes:
 If you specify Data Register, the network settings cannot be configured because they are acquired from the data registers.
 The current network settings can be checked from the status monitor.
Stopped
2015/DEC/01/TUE
13:30:40
Run
Edit Program
External Memory
Configurations
Function
Clock
Menu Languages
Backlight
Communications
Message Settings
Slave Number
CPU Network Settings
HMI Network Settings
Setting: Fixed
IP Address
192.168. 0. 10
HMI Network Settings
Setting:
Fixed
Data Register:
DHCP
