FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 7-23
7: HMI F UNCTION
8. Press the (OK) button to change the HMI module's Setting and to display the HMI Network Settings 1 screen.
Next, to change the IP address, subnet mask, gateway, preferred DNS server, and alternate DNS server, see the following pages.
 "Changing the IP address" on page 7-23, from step 2
 "Changing the subnet mask" on page 7-24, from step 2
 "Changing the gateway" on page 7-25, from step 2
 "Changing the preferred DNS server" on page 7-26, from step 2
 "Changing the alternate DNS server" on page 7-27, from step 2
9.
Press the (ESC) button to display the screen in the following diagram. Select Yes with the (down) button and press the
(OK) button.
■ Changing the IP address
1. Display the HMI Network Settings screen with the same procedure as steps 1 through 5 in "Changing the setting" on page 7-22.
2. Select IP Address on HMI Network Settings with the the (up) and (down) buttons and press the (OK) button.
The range is 000.000.000.000 to 255.255.255.255.
For example, change the IP address to 192.168.11.6.
3. Move the cursor with the (left) and (right) buttons and modify the value with the (up) and (down) buttons.
4. Press the (OK) button to change the HMI module's IP address to 192.168.11.6 and to display the following screen.
Next, to change the setting, subnet mask, gateway, preferred DNS server, and alternate DNS server, see the following pages.
 "Changing the setting" on page 7-22, from step 5
 "Changing the subnet mask" on page 7-24, from step 2
 "Changing the gateway" on page 7-25, from step 2
 "Changing the preferred DNS server" on page 7-26, from step 2
 "Changing the alternate DNS server" on page 7-27, from step 2
5.
Press the (ESC) button to display the screen in the following diagram.
Select Yes with the (down) button and press the (OK) button.
Setting: Fixed
IP Address
192.168. 1. 10
HMI Network Settings
Do you want to
configure network?
No
Yes
Setting: Fixed
IP Address
192.168. 1. 10
HMI Network Settings
Setting: Fixed
IP Address
192.168. 1. 10
HMI Network Settings
IP Address
192.168. 11. 6
Setting: Fixed
IP Address
192.168. 11. 6
HMI Network Settings
Do you want to
configure network?
No
Yes
