FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 7-21
7: HMI F UNCTION
■ Changing the alternate DNS server
1. Display the CPU Network Settings screen with the same procedure as steps 1 through 5 in "Changing the setting" on page 7-15.
2. Select Alternate DNS Server with the (up) and (down) buttons and press the (OK) button.
The range is 000.000.000.000 to 255.255.255.255.
For example, change the alternate DNS server to 192.168.1.201.
3. Move the cursor with the (left) and (right) buttons and modify the value with the (up) and (down) buttons.
4. Press the (OK) button to change the CPU module's alternate DNS server to 192.168.1.201 and to display the following
screen.
Next, to change the setting, IP address, subnet mask, gateway, and preferred DNS server, see the following pages.
 "Changing the setting" on page 7-15, from step 6
 "Changing the IP address" on page 7-17, from step 2
 "Changing the subnet mask" on page 7-18, from step 2
 "Changing the gateway" on page 7-19, from step 2
 "Changing the preferred DNS server" on page 7-20, from step 2
5.
Press the (ESC) button to display the screen in the following diagram.
Select Yes with the (down) button and press the (OK) button.
Setting: Fixed
IP Address
192.168. 1. 6
CPU Network Settings
Preferred DNS Server:
192.168. 1.200
Alternate DNS Server:
0. 0. 0. 0
Alternate DNS Server:
192.168. 1.201
Preferred DNS Server:
192.168. 1.200
Alternate DNS Server:
192.168. 1.201
Do you want to
configure network?
No
Yes
