7: HMI F UNCTION
7-18 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
■ Changing the subnet mask
1. Display the CPU Network Settings screen with the same procedure as steps 1 through 5 in "Changing the setting" on page 7-15.
2. Select Subnet Mask with the (up) and (down) buttons and press the (OK) button.
The range is 000.000.000.000 to 255.255.255.255.
For example, change the subnet mask to 255.255.254.0.
3. Move the cursor with the (left) and (right) buttons and modify the value with the (up) and (down) buttons.
4. Press the (OK) button to change the CPU module's subnet mask to 255.255.254.0 and to display the following screen.
Next, to change the setting, IP address, gateway, preferred DNS server, and alternate DNS server, see the following pages.
 "Changing the setting" on page 7-15, from step 6
 "Changing the subnet mask" on page 7-18, from step 2
 "Changing the gateway" on page 7-25, from step 2
 "Changing the preferred DNS server" on page 7-20, from step 2
 "Changing the alternate DNS server" on page 7-21, from step 2
5.
Press the (ESC) button to display the screen in the following diagram.
Select Yes with the (down) button and press the (OK) button.
Setting: Fixed
IP Address
192.168. 1. 6
CPU Network Settings
Subnet Mask:
255.255.255. 0
Default Gateway
0. 0. 0. 0
Subnet Mask

255.255.254. 0
Subnet Mask:
255.255.254. 0
Default Gateway
0. 0. 0. 0
Do you want to
configure network?
No
Yes
