Quantity of Applicable Analog I/O Modules
The maximum number of analog I/O modules that can be connected to the CPU module depends on the CPU module.
*1 When the expansion interface module (expander) is used, eight analog I/O modules can be connected to the right side of the expansion
interface module (expander). The number of modules that can be connected does not include the expansion interface module (expander).
*2 A maximum of 63 analog I/O modules can be connected using expansion interface modules (expander and remote master/slave). The number
of modules that can be connected does not include the expansion interface module.
Checking the Hardware Version Number
The analog I/O module hardware version number is printed on the side of the analog I/O module. The performance and
functionality of the analog I/O module will differ by its version, so check the version number before use.
CPU Module
Type No.
Quantity of Applicable
Analog I/O Modules
All-in-One CPU module
All-in-One CPU module
FC6A-C16R1AE, FC6A-C16R4AE
4 modules + 8 modules
*1
FC6A-C16R1CE, FC6A-C16R4CE
FC6A-C16K1CE, FC6A-C16K4CE
FC6A-C16P1CE, FC6A-C16P4CE
FC6A-C16R1DE, FC6A-C16R4DE
FC6A-C16K1DE, FC6A-C16K4DE
FC6A-C16P1DE, FC6A-C16P4DE
FC6A-C24R1AE, FC6A-C24R4AE
7 modules + 8 modules
*1
FC6A-C24R1CE, FC6A-C24R4CE
FC6A-C24K1CE, FC6A-C24K4CE
FC6A-C24P1CE, FC6A-C24P4CE
FC6A-C40R1AE, FC6A-C40R4AE
FC6A-C40R1CE, FC6A-C40R4CE
FC6A-C40K1CE, FC6A-C40K4CE
FC6A-C40P1CE, FC6A-C40P4CE
FC6A-C40R1DE, FC6A-C40R4DE
FC6A-C40K1DE, FC6A-C40K4DE
FC6A-C40P1DE, FC6A-C40P4DE
CAN J1939 All-in-One CPU
module
FC6A-C40R1AEJ, FC6A-C40R4AEJ
FC6A-C40R1CEJ, FC6A-C40R4CEJ
FC6A-C40K1CEJ, FC6A-C40K4CEJ
FC6A-C40P1CEJ, FC6A-C40P4CEJ
FC6A-C40R1DEJ, FC6A-C40R4DEJ
FC6A-C40K1DEJ, FC6A-C40K4DEJ
FC6A-C40P1DEJ, FC6A-C40P4DEJ
Plus CPU module
FC6A-D16R1CEE
63 modules
*2
FC6A-D16R4CEE
FC6A-D16K1CEE
FC6A-D16K4CEE
FC6A-D16P1CEE
FC6A-D16P4CEE
FC6A-D32K3CEE
FC6A-D32K4CEE
FC6A-D32P3CEE
FC6A-D32P4CEE
S/N:XXXXX-XXXXX V100
Version Number
