9: A
NALOG
I/O M
ODULES
9-12 FC6A S
ERIES
MICROS
MART
U
SER
’
S
M
ANUAL
FC9Y-B1722
(2) Data Type
The analog output value can be handled as the set data type. There are two data types for the analog outputs.
Yes: Supported, ―: Not supported
(3) Minimum and maximum values
The value written to the data register is output from the analog output. The minimum and maximum values that can be written
are determined by the set signal type and data type. A parameter setting error occurs when a value is set that exceeds the
minimum or maximum value.
The minimum and maximum values that correspond to the signal types and data types are as follows.
(4) Data
The analog output data for the analog output set with signal type (1) to minimum and maximum values (3) is stored in the data
registers in the END progressing of each scan. The actual analog output data is not guaranteed when the analog output status
(5) is a value other than "0". When M8025 (Maintain Outputs While Stopped) is on while stopped, the analog output value
immediately before stopping is output. When M8025 is off, the minimum value of the analog output is output. However, 0 V is
output when the signal type is -10 V to +10 V.
(5) Status
The status of the analog output data (4) is stored in data registers.
Data Type
FC6A-K2A1
FC6A-K2A4
FC6A-K4A1
FC6A-K4A4
FC6A-L06A1
FC6A-L06A4
FC6A-L03CN1
FC6A-L03CN4
Binary data YesYesYesYes
Optional range Yes Yes Yes Yes
Signal Type
Data Type
Binary Data Optional Range
*1
0 to 10 V 0 to 4,095 -32,768 to 32,767
-10 to +10 V -2,048 to 2,047 -32,768 to 32,767
0 to 20 mA 0 to 4,095 -32,768 to 32,767
4 to 20 mA 0 to 4,095 -32,768 to 32,767
*1 The minimum and maximum values can be set only when the data type is set to optional range. Set the minimum and maximum values
between -32,768 and 32,767.
Status Description
0 Operating normally
1 Reserved
2 Initializing
3 Parameter setting error
4 Hardware fault (external power supply error)
5 to 65,535 Reserved
