9: A NALOG I/O M ODULES
9-18 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Filter
The setting value is rounded by 50.
When 50,001 to 65,535 is stored for the setting value, the filter operates as the maximum value of 50,000 ms.
Thermistor constant
Analog Output Module
The detailed device allocation for analog output modules is as follows.
For the parameter setting values, see "Analog Output Parameter Setting Values" on page 9-19.
Setting Value Filter
00 ms
50 50 ms
100 100 ms
150 150 ms
……
50,000 50,000 ms
Range Thermistor Constant
0 to 65,535 R0
-32,768 to 32,767 T0
-32,768 to 32,767 B
Channel
Parameter R/W
FC6A-K2A1
FC6A-K2A4
FC6A-K4A1
FC6A-K4A4
I/O No.
Output
CH0
Analog output data R +0 +0
Analog output status R +1 +1
CH1
Analog output data R +2 +2
Analog output status R +3 +3
CH2
Analog output data R ― +4
Analog output status R ― +5
CH3
Analog output data R ― +6
Analog output status R ― +7
When use the operation setting data registers,
the following data registers are used.
CH0
Signal type R/W +4 +8
Data type R/W +5 +9
Minimum value R/W +6 +10
Maximum value R/W +7 +11
CH1
Signal type R/W +8 +12
Data type R/W +9 +13
Minimum value R/W +10 +14
Maximum value R/W +11 +15
CH2
Signal type R/W ― +16
Data type R/W ― +17
Minimum value R/W ― +18
Maximum value R/W ― +19
CH3
Signal type R/W ― +20
Data type R/W ― +21
Minimum value R/W ― +22
Maximum value R/W ― +23
