FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 9-19
9: A NALOG I/O M ODULES
Analog Output Parameter Setting Values
The parameter setting values are as follows.
Signal type
If the setting value is outside the range, a parameter setting error will occur.
Data type
If the setting value is 2 to 65,535, a parameter setting error will occur.
Minimum and maximum values
The minimum and maximum values can be set only when the data type is set to optional range. Set the minimum and maximum
values between -32,768 and 32,767.
Setting Value Signal Type
0Unused
1 0 to 10 V
2 -10 to +10 V
3 0 to 20 mA
4 4 to 20 mA
Setting Value Data type
0Binary data
1Optional range
