IDEC MICROSmart FC6A Series User Manual

9: A NALOG I/O M ODULES
9-20 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Mixed Analog I/O Module
The detailed device allocation for mixed analog I/O modules is as follows. For the parameter setting values for analog inputs, see
"Analog Input Parameter Setting Values" on page 9-17. For analog outputs, see "Analog Output Parameter Setting Values" on page
9-19.
Channel
Parameter R/W
FC6A-L06A1
FC6A-L06A4
FC6A-L03CN1
FC6A-L03CN4
No. I/O I/O
CH0
Analog data R
Input
+0
Input
+0
Analog status R +1 +1
CH1
Analog data R +2 +2
Analog status R +3 +3
CH2
Analog data R +4
Output
+4
Analog status R +5 +5
CH3
Analog data R +6 ――
Analog status R +7 ――
CH4
Analog data R
Output
+8 ――
Analog status R +9 ――
CH5
Analog data R +10 ――
Analog status R +11 ――
When use the operation setting data registers, the following data registers are used.
CH0
Signal type R/W
Input
+12
Input
+6
Data type R/W +13 +7
Minimum value R/W +14 +8
Maximum value R/W +15 +9
Filter value R/W +16 +10
CH1
Signal type R/W +17 +11
Data type R/W +18 +12
Minimum value R/W +19 +13
Maximum value R/W +20 +14
Filter value R/W +21 +15
CH2
Signal type R/W +22
Output
+16
Data type R/W +23 +17
Minimum value R/W +24 +18
Maximum value R/W +25 +19
Filter value R/W +26 ―
CH3
Signal type R/W +27 ――
Data type R/W +28 ――
Minimum value R/W +29 ――
Maximum value R/W +30 ――
Filter value R/W +31 ――
CH4
Signal type R/W
Output
+32 ――
Data type R/W +33 ――
Minimum value R/W +34 ――
Maximum value R/W +35 ――
Filter value R/W ―――
CH5
Signal type R/W +36 ――
Data type R/W +37 ――
Minimum value R/W +38 ――
Maximum value R/W +39 ――
Filter value R/W ―――
