Function Specifications
■ CPU Module Performance
*1 1 step is equivalent to 8 bytes.
*2 As given below, certain digital I/O cartridges cannot be used in cartridge slot 3 depending on the configuration of expansion modules.
Limitations on Using Digital I/O Cartridges
*3 A maximum of two or three cartridges can be used by connecting the HMI module.
*4 There are limitations on the maximum number of outputs that can be simultaneously turned on.
For details, see "Connection Restrictions When Expanding the PLC" on page 3-37.
*5 The maximum number of expansion modules that can be connected can be increased by using the expansion interface module. For details, see
"Expansion Interface Modules" on page 2-143.
Type No.
FC6A-C16R1AE
FC6A-C16R4AE
FC6A-C16R1CE
FC6A-C16R4CE
FC6A-C16K1CE
FC6A-C16K4CE
FC6A-C16P1CE
FC6A-C16P4CE
FC6A-C16R1DE
FC6A-C16R4DE
FC6A-C16K1DE
FC6A-C16K4DE
FC6A-C16P1DE
FC6A-C16P4DE
FC6A-C24R1AE
FC6A-C24R4AE
FC6A-C24R1CE
FC6A-C24R4CE
FC6A-C24K1CE
FC6A-C24K4CE
FC6A-C24P1CE
FC6A-C24P4CE
FC6A-C40R1AE
FC6A-C40R4AE
FC6A-C40R1CE
FC6A-C40R4CE
FC6A-C40K1CE
FC6A-C40K4CE
FC6A-C40P1CE
FC6A-C40P4CE
FC6A-C40R1DE
FC6A-C40R4DE
FC6A-C40K1DE
FC6A-C40K4DE
FC6A-C40P1DE
FC6A-C40P4DE
FC6A-C40R1AEJ
FC6A-C40R4AEJ
FC6A-C40R1CEJ
FC6A-C40R4CEJ
FC6A-C40K1CEJ
FC6A-C40K4CEJ
FC6A-C40P1CEJ
FC6A-C40P4CEJ
FC6A-C40R1DEJ
FC6A-C40R4DEJ
FC6A-C40K1DEJ
FC6A-C40K4DEJ
FC6A-C40P1DEJ
FC6A-C40P4DEJ
Program
Capacity
*1
Program Data
72,000 bytes
(9,000 steps)
* Writable during run-time
384,000 bytes
(48,000 steps)
* Not writable during run-time
640,000 bytes
(80,000 steps)
* Not writable during
run-time
Comment Data 256,000 bytes 256,000 bytes
I/O Expansion
Basic Expansion 4777
Expansion Interface 8888
Cartridges
*2 *3
2233
I/O Points
Basic
Input 9142424
Output 7101616
Basic Expansion
*4
128 224 224 224
Expansion Interface
*5
256 256 256 256
Cartridges
*2 *3
881212
User Program Download 1,000 times
Control System
Stored program system
Instructions
Basic Instructions 42 types
Advanced Instructions 124 types
Processing Speed
Basic Instruction 0.042 ms/1,000 steps
END Processing 1 ms
Internal Relay 12,400
Shift Register 256
Data Register 54,000
Counter (adding, reversible) 512
Timer (1 ms, 10 ms, 100 ms, 1 s) 1,024
Configuration of Expansion Modules Digital I/O Cartridges That Cannot Be Used in Cartridge Slot 3
FC6A-N32B3×15 FC6A-PN4
FC6A-T32K3 and FC6A-T32P3×15 FC6A-PTK4, FC6A-PTS4
