FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-17
2: P RODUCT S PECIFICATIONS
Backup Function
*1 To prepare for when the battery dies, the contents of RAM (internal relays, shift registers, counters, and data registers) can be saved to non-
volatile memory. For how to save the contents of RAM, see "SD Memory Card" on page 11-1.
*2 The battery is primarily consumed by backup current while unpowered. However, the ambient environment (temperature and humidity) while
unpowered and powered also affects consumption. In particular, battery life is greatly reduced in a high-temperature and high-humidity
environment, so replacement is recommended every year when the effect of the ambient environment (temperature and humidity) while
unpowered and powered is included.
*3 Replacement while powered and replacement while power is supplied from the USB bus are also possible. For the replacement method, see
"Replacing the Backup Battery" on page 3-34.
Clock Function
Self-diagnostic Functions
Input Filter
0 ms (no filter), 3 to 15 ms selectable (in 1 ms increments)
Catch Input/Interrupt Input
High-speed Counter
Backup Data RAM (internal relays, shift registers, counters, data registers)
*1
, clock
Backup Battery
Lithium ion primary cell (A battery is included with the product. The model of battery to be included
with the product cannot be specified.)
Panasonic: BR2032/CR2032A/CR2032B, Murata: CR2032X/CR2032W
Battery Life Guaranteed 1 year, replacement recommended every 4 years (+25°C)
*2
Replaceability Replace within 1 minute after power off (recommended)
*3
Accuracy ±30 seconds/month at 25°C
 Keep data
 User program (ROM) CRC check
 Timer/counter preset value change check
 User program syntax check
 User program execution check
 Watchdog timer check
 User program download check
 Power failure
 Clock error
 Data link connection check
 Expansion bus initialization check
 System check
 SD memory card transfer check
 SD memory card access check
High-speed 4 Points (I0, I1, I6, I7)
Minimum turn on pulse width: 5 μs
Minimum turn off pulse width: 5 μs
Medium-speed 2 Points (I3, I4)
Minimum turn on pulse width: 35 μs
Minimum turn off pulse width: 35 μs
Maximum Counter
Frequency and Points
Single-phase, two-phase common: 100 kHz (single-phase 4 points max, two-phase 2 points max)
Single-phase dedicated: 5 kHz (2 points)
Count Range
Single-phase, two-phase common: 0 to 4,294,967,295 (32 bits)
Single-phase dedicated: 0 to 4,294,967,295 (32 bits)
Operation Mode Rotary encoder mode, adding counter mode, frequency measurement mode
