IDEC MICROSmart FC6A Series User Manual

2: P RODUCT S PECIFICATIONS
2-18 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Pulse Output (Transistor Output Type Only)
Function Switch
Run/Stop Methods
Sensor External Output Power (AC Power Type Only)
*1
*1 When the FC6A Series MICROSmart is used in expanded ambient operating temperatures (-25 to -10°C and 55 to 65°C), sensor external output
power cannot be used.
USB Port
Part No.
FC6A-C16K1CE
FC6A-C16K4CE
FC6A-C16P1CE
FC6A-C16P4CE
FC6A-C16K1DE
FC6A-C16K4DE
FC6A-C16P1DE
FC6A-C16P4DE
FC6A-C24K1CE
FC6A-C24K4CE
FC6A-C24P1CE
FC6A-C24P4CE
FC6A-C40K1CE
FC6A-C40K4CE
FC6A-C40P1CE
FC6A-C40P4CE
FC6A-C40K1DE
FC6A-C40K4DE
FC6A-C40P1DE
FC6A-C40P4DE
FC6A-C40K1CEJ
FC6A-C40K4CEJ
FC6A-C40P1CEJ
FC6A-C40P4CEJ
FC6A-C40K1DEJ
FC6A-C40K4DEJ
FC6A-C40P1DEJ
FC6A-C40P4DEJ
Points 4
Maximum output
pulse frequency
Q0,Q1: 100kHz
Q2,Q3: 5kHz
Q0,Q2,Q4,Q6: 100kHz
Reversible control
Single-pulse output mode: 2axis (Q0-Q3)
Dual-pulse output mode: 1axis (Q0-Q1)
Single-pulse output mode: 4axis (Q0-Q7)
Dual-pulse output mode: 4axis (Q0-Q7)
PWM output
Duty cycle: 0.1 to 100.0 (increments of 0.1%)
Output pulse frequency: 15 to 5,000 (increments of 1Hz)
: 4 points(Q0-Q3)
*Q0,Q1:Adjust min. 5μs as ON time, and min. 15μs as OFF time.
*Q2,Q3:Adjust min. 100μs as ON/OFF time .
Duty cycle: 0.1 to 100.0 (increments of 0.1%)
Output pulse frequency: 15 to 5,000
(increments of 1Hz)
: 4 points(Q0,Q2,Q4,Q6)
*Adjust min. 5μs as ON time, and min. 15μs
as OFF time.
Points 1 (2 position slide switch)
Function
Program run/stop
The function can be set in the function area settings (default setting: enabled).
 Power on/off
 WindLDR RUN/STOP command
 Function switch operation
 Special internal relay (M8000) operation
 Operation of stop input and reset input
Type No.
FC6A-C16R1AE, FC6A-C16R4AE, FC6A-C24R1AE, FC6A-C24R4AE, FC6A-C40R1AE,
FC6A-C40R4AE, FC6A-C40R1AEJ, FC6A-C40R4AEJ
Output Voltage/Current 24 V (+10%, -15%)/250 mA (however, capacitive load is 2,500 μF or lower)
Overload Detection
Not possible (an overcurrent protection circuit is built in, but there is a risk of damage from a
long term short circuit.)
Isolation between Internal Circuit Isolated
Points 1
Communication Type USB2.0 Full speed, CDC class
Communication Functions Capable of maintenance communication with a PC
Connector USB mini-B
Isolation between Internal Circuit Not isolated
Available Function when FC6A is Powered
by USB
Downloading/uploading user programs, downloading system software, data file manager
