(2) Signal Type
The signal type that can be set differs according to the analog I/O cartridge model. Select the analog I/O cartridge that
corresponds to the user application and set the signal type.
For details on signal type, see "Analog I/O Cartridge Specifications" on page 10-9.
(3) Data Type
The analog value can be handled in the range of the specified data type (minimum value to maximum value). The data types are
as follows.
(4) Minimum, maximum values of analog value linear conversion
When Data Type is set to "Optional range", these values set the minimum and maximum when performing a linear conversion
of the analog value. The minimum and maximum values can be set to any value in the range of -32,768 to 32,767. However, the
minimum value must be set to a value smaller than the maximum value.
(5) Linear conversion range of analog input value when set to Celsius or Fahrenheit
When the data type is set to Celsius or Fahrenheit, the analog input value is linearly converted in the range of the following
table.
Data Type Description
Binary data The analog value can be stored in the range of 0 to 4,095.
Optional range
The analog value can be stored in the range of minimum value to maximum value. The minimum and maximum
values can be set in the range of -32,768 to 32,767. For the minimum and maximum values, see "(4) Minimum,
maximum values of analog value linear conversion" on page 10-12.
Celsius
The analog value can be stored in the linear conversion range of the temperature sensor set as the data type.
For details, see the analog input value linear conversion range when set to Celsius or Fahrenheit.
Fahrenheit
Signal Type
Celsius Fahrenheit
Temperature (0.1°C) Analog Input Value Temperature (0.1°F) Analog input value
Type K thermocouple -200.0 to 1,300.0 -2,000 to 13,000 -328.0 to 2,3720.0 -3,280 to 23,720
Type J thermocouple -200.0 to 1,000.0 -2,000 to 10,000 -328.0 to 1,832.0 -3,280 to 18,320
Type R thermocouple 0.0 to 1,760.0 0 to 17,600 32.0 to 3,200.0 320 to 32,000
Type S thermocouple 0.0 to 1,760.0 0 to 17,600 32.0 to 3,200.0 320 to 32,000
Type B thermocouple 0.0 to 1,820.0 0 to 18,200 32.0 to 3,308.0 320 to 33,080
Type E thermocouple -200.0 to 800.0 -2,000 to 8,000 -328.0 to 1,472.0 -3,280 to 14,720
Type T thermocouple -200.0 to 400.0 -2,000 to 4,000 -328.0 to 752.0 -3,280 to 7,520
Type N thermocouple -200.0 to 1,300.0 -2,000 to 13,000 -328.0 to 2,372.0 -3,280 to 23,720
Type C thermocouple 0.0 to 2,315.0 0 to 23,150 32.0 to 4,199.0 320 to 41,990
Pt100 -200.0 to 850.0 -2,000 to 8,500 -328.0 to 1,562.0 -3,280 to 15,620
Pt1000 -200.0 to 600.0 -2,000 to 6,000 -328.0 to 1,112.0 -3,280 to 11,120
Ni100 -60.0 to 180.0 -600 to 1,800 -76.0 to 356.0 -760 to 3,560
Ni1000 -60.0 to 180.0 -600 to 1,800 -76.0 to 356.0 -760 to 3,560
