CAN J1939 All-in-One CPU Modules
*1 Screw fastened type
*2 Push-in type
Plus CPU Modules
*1 Screw fastened type
*2 Push-in type
*3 Screw fastened type (Power supply terminals)
*4 Push-in type (Power supply terminals)
Power
Voltage
Input Type Output Type
I/O Points
(Input Points/
Output Points)
Type No.
Terminal
Specification
100-240V
AC
24V DC input
shared sink/source
Relay output, 2 A/point
40 (24/16)
FC6A-C40R1AEJ
Removable
terminal block
(5.08 mm pitch)
*1
FC6A-C40R4AEJ
*2
24V DC
FC6A-C40R1CEJ
*1
FC6A-C40R4CEJ
*2
Transistor sink output
24V DC, 0.5 A/point
FC6A-C40K1CEJ
*1
FC6A-C40K4CEJ
*2
Transistor protection source output
24V DC, 0.5 A/point
FC6A-C40P1CEJ
*1
FC6A-C40P4CEJ
*2
12V DC
12V DC input
shared sink/source
Relay output, 2 A/point
40 (24/16)
FC6A-C40R1DEJ
Removable
terminal block
(5.08 mm pitch)
*1
FC6A-C40R4DEJ
*2
Transistor sink output
12V DC, 0.5 A/point
FC6A-C40K1DEJ
*1
FC6A-C40K4DEJ
*2
Transistor protection source output
12V DC, 0.5 A/point
FC6A-C40P1DEJ
*1
FC6A-C40P4DEJ
*2
Power
Voltage
Input Type Output Type
I/O Points
(Input Points/
Output Points)
Type No.
Terminal
Specification
24V DC
24V DC input
shared sink/source
Relay output, 2 A/point
16 (8/8)
FC6A-D16R1CEE
Removable
terminal block
(3.81 mm pitch)
*1
FC6A-D16R4CEE
*2
Transistor sink output
24V DC, 0.5 A/point
FC6A-D16K1CEE
*1
FC6A-D16K4CEE
*2
Transistor protection source output
24V DC, 0.5 A/point
FC6A-D16P1CEE
*1
FC6A-D16P4CEE
*2
Transistor sink output
24V DC, 0.5 A/point
32 (16/16)
FC6A-D32K3CEE 20-pin MIL
connector (Input
terminals,
output
terminals)
*3
FC6A-D32K4CEE
*4
Transistor protection source output
24V DC, 0.5 A/point
FC6A-D32P3CEE
*3
FC6A-D32P4CEE
*4
