FC6A S
ERIES
MICROS
MART
U
SER
’
S
M
ANUAL
FC9Y-B1722 A-3
A
PPENDIX
Expansion Modules
Digital I/O Modules
*1 24V DC input for products with a version number lower than V400. For details on the version number of modules, see "Checking the Version
Number" on page 2-1.
*2 Screw fastened type
*3 Push-in type
Input Type Output Type
I/O Points
(Input Points/
Output Points)
Type No. Terminal Specification
12/24V DC input
*1
shared sink/source
—
8 (8/0)
FC6A-N08B1
Removable terminal block (5.08 mm pitch)
*2
FC6A-N08B4
*3
16 (16/0)
FC6A-N16B1
Removable terminal block (3.81 mm pitch)
*2
FC6A-N16B4
*3
16 (16/0) FC6A-N16B3
20-pin MIL connector
32 (32/0) FC6A-N32B3
100-120V AC input — 8 (8/0)
FC6A-N08A11
Removable terminal block (5.08 mm pitch)
*2
FC6A-N08A14
*3
—
Relay output, 2 A/point
8 (0/8)
FC6A-R081
Removable terminal block (5.08 mm pitch)
*2
FC6A-R084
*3
16 (0/16)
FC6A-R161
Removable terminal block (3.81 mm pitch)
*2
FC6A-R164
*3
Transistor sink output
12/24V DC, 0.5 A/point
*1
8 (0/8)
FC6A-T08K1
Removable terminal block (5.08 mm pitch)
*2
FC6A-T08K4
*3
Transistor protection source output
24V DC, 0.5 A/point
8 (0/8)
FC6A-T08P1
*2
FC6A-T08P4
*3
Transistor sink output
12/24V DC, 0.5 A/point
*1
16 (0/16)
FC6A-T16K1
Removable terminal block (3.81 mm pitch)
*2
FC6A-T16K4
*3
Transistor protection source output
24V DC, 0.5 A/point
16 (0/16)
FC6A-T16P1
*2
FC6A-T16P4
*3
Transistor sink output
12/24V DC, 0.1 A/point
*1
16 (0/16) FC6A-T16K3
20-pin MIL connector
Transistor protection source output
24V DC, 0.1 A/point
16 (0/16) FC6A-T16P3
Transistor sink output
12/24V DC, 0.1 A/point
*1
32 (0/32) FC6A-T32K3
Transistor protection source output
24V DC, 0.1 A/point
32 (0/32) FC6A-T32P3
24V DC input
shared sink/source
Relay output, 2 A/point
8 (4/4)
FC6A-M08BR1
Removable terminal block (5.08 mm pitch)
*2
FC6A-M08BR4
*3
24 (16/8)
FC6A-M24BR1
Removable terminal block (3.81 mm pitch)
*2
FC6A-M24BR4
*3
To Next Page
