A PPENDIX
A-4 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Analog I/O Modules
*1 Screw fastened type
*2 Push-in type
PID Modules
*1 Screw fastened type
*2 Push-in type
Communication Module
*1 Screw fastened type
*2 Push-in type
Power
Voltage
Input Type Output Type
I/O Points
(Input Points/
Output Points)
Type No. Terminal Specification
12/24V
DC
Analog input
(voltage/current)
—
2 (2/0)
FC6A-J2C1
Removable terminal block
(5.08 mm pitch)
*1
FC6A-J2C4
*2
4 (4/0)
FC6A-J4A1
Removable terminal block
(3.81 mm pitch)
*1
FC6A-J4A4
*2
8 (8/0)
FC6A-J8A1
Removable terminal block
(3.81 mm pitch)
*1
FC6A-J8A4
*2
—
Analog output
(voltage/current)
2 (0/2)
FC6A-K2A1
Removable terminal block
(5.08 mm pitch)
*1
FC6A-K2A4
*2
24V DC
—
Analog output
(voltage/current)
4 (0/4)
FC6A-K4A1
Removable terminal block
(5.08 mm pitch)
*1
FC6A-K4A4
*2
Analog input
(voltage/current)
Analog output
(voltage/current)
6 (4/2)
FC6A-L06A1
Removable terminal block
(3.81 mm pitch)
*1
FC6A-L06A4
*2
12/24V
DC
Analog input
(voltage/current/
thermocouple/resistance
thermometer)
Analog output
(voltage/current)
3 (2/1)
FC6A-L03CN1
Removable terminal block
(5.08 mm pitch)
*1
FC6A-L03CN4
*2
Analog input
(voltage/current/
thermocouple/resistance
thermometer)
—
4 (4/0)
FC6A-J4CN1
Removable terminal block
(3.81 mm pitch)
*1
FC6A-J4CN4
*2
Analog input
(thermocouple)
4 (4/0)
FC6A-J4CH1Y
Removable terminal block
(3.81 mm pitch)
*1
FC6A-J4CH4Y
*2
Analog input
(thermocouple/
thermistor/resistance)
8 (8/0)
FC6A-J8CU1
Removable terminal block
(3.81 mm pitch)
*1
FC6A-J8CU4
*2
Power
Voltage
Input Type Output Type
I/O Points
(Input Points/
Output Points)
Type No. Terminal Specification
24V DC
Analog input
(voltage/current/
thermocouple/resistance
thermometer)
Relay output
240V AC, 2 A/30V DC, 2 A
4 (2/2)
FC6A-F2MR1
Removable terminal block
(3.81 mm pitch)
*1
FC6A-F2MR4
*2
Analog input
(voltage/current/
thermocouple/resistance
thermometer)
Transistor source output
12V DC/analog output
(current)
4 (2/2)
FC6A-F2M1
Removable terminal block
(3.81 mm pitch)
*1
FC6A-F2M4
*2
Name Function/purpose
I/O Points
(Input Points/
Output Points)
Type No. Terminal Specification
Communication
module
RS232C/RS485 communication —
FC6A-SIF52
Direct-mounting terminal block
(3.81 mm pitch)
*1
FC6A-SIF524
*2
