FC6A S

ERIES

MICROS

MART

SER

’

ANUAL

FC9Y-B1722 A-5

PPENDIX

Expansion Interface Modules

*1 Screw fastened type

*2 Push-in type

HMI Module

Cartridge Base Module

Cartridges

Power

Voltage

Name Function/purpose

I/O Points

(Input Points/

Output Points)

Type No. Terminal Specification

24V DC

Expander

Increases the number

of expansion modules

that can be connected

—

FC6A-EXM2

Removable terminal block

(5.08 mm pitch)

FC6A-EXM24

Remote master — FC6A-EXM1M —

Remote slave —

FC6A-EXM1S

Removable terminal block

(5.08 mm pitch)

FC6A-EXM1S4

Name Function/purpose

I/O Points

(Input Points/

Output Points)

Type No. Terminal Specification

HMI module HMI module with web server function — FC6A-PH1 —

Name Function/purpose

I/O Points

(Input Points/

Output Points)

Type No. Terminal Specification

Cartridge base

module

Expands cartridge slots for the Plus

CPU module

— FC6A-HPH1 —

Name Function/purpose

I/O Points

(Input Points/

Output Points)

Type No. Terminal Specification

Digital I/O cartridge

12/24V DC input shared sink/source 4 (4/0) FC6A-PN4
