A-6 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Maintenance Parts
*1 Appropriate screw fastened type removable termal blocks are contained in the purchased modules.
Type Type No. Specifications
FC6A Series CPU module
connector with analog input cable
FC4A-PMAC2PN02
Cable length: 1 m (3.28 feet) (2 items)
Compatible with the FC4A Slim Type, the FC5A Slim Type,
and the FC6A Series MICROSmart
FC6A Series CPU module mounting hook
FC6A Series HMI module mounting hook
FC6A-PSP1PN05 Direct/DIN-rail mounting hook (5 items)
FC6A Series expansion module mounting hook
FC6A Series expansion interface module mounting hook
FC6A-PSP2PN05 Direct/DIN-rail mounting hook (5 items)
FC6A Series CPU module power supply terminal block
connector
FC6A-PMTD03PN02 5.08 mm pitch, 3-pin, screw fastened type (2 items)
*1
FC6A Series expansion interface module power supply terminal
block connector
FC6A-PMTB03PN02 5.08 mm pitch, 3-pin, screw fastened type (2 items)
*1
FC6A Series CPU module, CAN J1939 All-in-One CPU module
CAN communication terminal block connector
FC6A-PMTE05PN02 5.08 mm pitch, 5-pin, screw fastened type (2 items)
*1
FC6A Series CPU module removable terminal block
FC6A-PMTA08PN02 5.08 mm pitch, 8-pin, screw fastened type (2 items)
*1
FC6A-PMTA09PN02 5.08 mm pitch, 9-pin, screw fastened type (2 items)
*1
FC6A-PMTA10PN02 5.08 mm pitch, 10-pin, screw fastened type (2 items)
*1
FC6A-PMTA12PN02 5.08 mm pitch, 12-pin, screw fastened type (2 items)
*1
FC6A-PMTA13PN02 5.08 mm pitch, 13-pin, screw fastened type (2 items)
*1
FC6A Series Plus CPU module inputs removable terminal block
FC6A-PMSCN10PN02 3.81 mm pitch, 10-pin, push-in type (2 items)
FC6A-PMTCN10PN02 5.08 mm pitch, 10-pin, screw fastened type (2 items)
*1
FC6A Series Plus CPU module relay outputs removable terminal
block
FC6A-PMSCR11PN02 3.81 mm pitch, 11-pin, push-in type (2 items)
FC6A-PMTCR11PN02 5.08 mm pitch, 11-pin, screw fastened type (2 items)
*1
FC6A Series Plus CPU module sink outputs removable terminal
block
FC6A-PMSCK11PN02 3.81 mm pitch, 11-pin, push-in type (2 items)
FC6A-PMTCK11PN02 5.08 mm pitch, 11-pin, screw fastened type (2 items)
*1
FC6A Series Plus CPU module protection source outputs
removable terminal block
FC6A-PMSCP11PN02 3.81 mm pitch, 11-pin, push-in type (2 items)
FC6A-PMTCP11PN02 5.08 mm pitch, 11-pin, screw fastened type (2 items)
*1
FC6A Series Plus CPU module power supply removable terminal
block
FC6A-PMSDC03PN02 5.08 mm pitch, 3-pin, push-in type (2 items)
FC6A Series expansion module removable terminal block
FC6A-PMSB11PN02 5.08 mm pitch, 11-pin, push-in type (2 items)
FC6A-PMSC10PN02 3.81 mm pitch, 10-pin, push-in type (2 items)
FC6A-PMSC11PN02 3.81 mm pitch, 11-pin, push-in type (2 items)
FC6A-PMSC17PN02 3.81 mm pitch, 17-pin, push-in type (2 items)
FC6A Series expansion interface module removable terminal
block
FC6A-PMTB11PN02 5.08 mm pitch, 11-pin, screw fastened type (2 items)
*1
FC6A-PMTC10PN02 3.81 mm pitch, 10-pin, screw fastened type (2 items)
*1
FC6A-PMTC11PN02 3.81 mm pitch, 11-pin, screw fastened type (2 items)
*1
FC6A-PMTC17PN02 3.81 mm pitch, 17-pin, screw fastened type (2 items)
*1
FC6A Series expansion interface module power supply
removable terminal block
FC6A-PMSB03PN02 5.08 mm pitch, 3-pin, push-in type (2 items)
FC6A Series CPU module battery holder FC6A-BH1PN02 Battery holder (2 items)
