FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 A-7
A PPENDIX
Manuals
Application Software
Option Cables (Sold Separately)
*1 The "□" in the I/O terminal type numbers indicates the terminal shape.
T: Touch-down terminal block, S: Captive screw terminal block
*2 Use the FC6A-KC1C for products other than the HG2G-5FT22TF Series.
Options (Sold Separately)
*1 Sold in Japan only.
Type Type No. Specifications
FC6A Series MICROSmart User’s Manual
FC9Y-B1721 Japanese
FC9Y-B1722 English
FC9Y-B1723 Chinese (PDF manual only)
FC6A Series MICROSmart Ladder Programming Manual
FC9Y-B1725 Japanese
FC9Y-B1726 English
FC9Y-B1727 Chinese (PDF manual only)
FC6A Series MICROSmart Communication Manual
FC9Y-B1729 Japanese
FC9Y-B1730 English
FC9Y-B1731 Chinese (PDF manual only)
FC6A Series MICROSmart PID Module User’s Manual
FC9Y-B1733 Japanese
FC9Y-B1734 English
FC9Y-B1735 Chinese (PDF manual only)
Product Name Type No. Specifications
Automation Organizer SW1A-W1C
Package software containing the programming software
"WindLDR"
Product Name Type No. Function
Shielded flat I/O cable (0.5 m [1.64 feet]) FC9Z-H050A20
Shielded, 20-pin straight cable for use with I/O modules
This can be used with IDEC I/O terminals.
The type numbers of the supported I/O terminals are shown below.
BX1D-□20A,
*1
BX1F-□20A,
*1
BX7D-BT16A1T
(16-point relay output)
Shielded flat I/O cable (1 m [3.28 feet]) FC9Z-H100A20
Shielded flat I/O cable (2 m [6.56 feet]) FC9Z-H200A20
Shielded flat I/O cable (3 m [9.84 feet]) FC9Z-H300A20
Non-shielded flat I/O cable (0.5 m [1.64 feet]) FC9Z-H050B20
Non-shielded, 20-pin straight cable for use with I/O modules
This can be used with IDEC I/O terminals.
The type numbers of the supported I/O terminals are shown below.
BX1D-□20A
*1
, BX1F-□20A
*1
, BX7D-BT16A1T
(16-point relay output)
Non-shielded flat I/O cable (1 m [3.28 feet]) FC9Z-H100B20
Non-shielded flat I/O cable (2 m [6.56 feet]) FC9Z-H200B20
Non-shielded flat I/O cable (3 m [9.84 feet]) FC9Z-H300B20
External device/O/I communication cable FC6A-KC1C
Cable for connecting external devices, IDEC displays (HG4G/3G/2G),
and general-purpose display devices (cable length: 5 m [16.4 feet])
RJ45 connector/loose wires (1 item)
O/I communication cable FC6A-KC2C
Cable dedicated for connecting IDEC displays (HG4G/3G/2G
*2
) (cable
length: 5 m [16.4 feet])
RJ45 connector/D-sub 9-pin connector (1 item)
Product Name Function Type No. Comments
35 mm wide DIN rail (length: 1,000 mm) Aluminum, used when mounting on DIN rail BAA1000PN10 10 items
35 mm wide DIN rail (length: 1,000 mm) Steel, used when mounting on DIN rail BAP1000PN10 10 items
Bracket
Used to fix CPU modules, expansion modules, and HMI
modules on a rail
BNL6PN10 10 items
20-pin connector 20-pin MIL connector for an expansion module FC4A-PMC20PNO2 2 items
USB maintenance cable
Cable length: 2 m (6.7 feet)
USB cable used to connect the PC and the PLC
<Connector> A: mini B
HG9Z-XCM42 1 item
USB-mini B port extension cable
(cable length: 1 m [3.28 feet])
USB cable used to extend the USB-mini B port to the panel
surface
HG9Z-XCE21 1 item
USB cable retention pin Used to keep the USB cable constantly connected HG9Z-XU1PN05 5 items
Replacement battery for CPU module
CR2032W backup battery
(1 battery is included with the PLC unit.)
HG9Z-XR2 1 item
*1
