IDEC MICROSmart FC6A Series User Manual

2: P RODUCT S PECIFICATIONS
2-56 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Clock Function
Self-diagnostic Functions
Input Filter
0 ms (no filter), 3 to 15 ms (selectable in increments of 1 ms)
Catch Input/Interrupt Input
High-speed Counter
Pulse Output (Transistor Output Type Only)
Function Switch
Analog Potentiometer
Analog Input
Accuracy ±30 seconds/month at 25°C
 Keep data
 User program (ROM) CRC check
 Timer/counter preset value change check
 User program syntax check
 User program execution check
 Watchdog timer check
 User program download check
 Power failure
 Clock error
 Data link connection check
 Expansion bus initialization check
 System check
 SD memory card transfer check
 SD memory card access check
Type No.
FC6A-D16R1CEE, FC6A-D16R4CEE
FC6A-D16K1CEE, FC6A-D16K4CEE
FC6A-D16P1CEE, FC6A-D16P4CEE
FC6A-D32K3CEE, FC6A-D32K4CEE
FC6A-D32P3CEE, FC6A-D32P4CEE
I0 to I7 0 ms (no filter), 3 to 15 ms (selectable in increments of 1 ms)
I10 to I13 —
0 ms (no filter),
3 to 15 ms selectable (in 1 ms increments)
I14 to I17 —3 ms fixed
Type No.
FC6A-D16R1CEE, FC6A-D16R4CEE
FC6A-D16K1CEE, FC6A-D16K4CEE
FC6A-D16P1CEE, FC6A-D16P4CEE
FC6A-D32K3CEE, FC6A-D32K4CEE
FC6A-D32P3CEE, FC6A-D32P4CEE
High-speed 6 Points (I0, I1, I3, I4, I6,
I7)
Minimum turn on pulse width: 5 μs
Minimum turn off pulse width: 5 μs
Medium-speed 3 Points (I11, I12, I13) —
Minimum turn on pulse width: 35 μs
Minimum turn off pulse width: 35 μs
Maximum Counter Frequency and Points Single-phase, two-phase common: 100 kHz (single-phase 6 points max, two-phase 3 points max)
Count Range Single-phase, two-phase common: 0 to 4,294,967,295 (32 bits)
Operation Mode Rotary encoder mode, adding counter mode, frequency measurement mode
Points
High-speed Output
(100 kHz)
4
Points 1 (2 position slide switch)
Function
Program run/stop
The function can be set in the function area settings (default setting: enabled).
Points 1
Data Resolution 0 to 1,000
Points 1
Input Range 0 to 10 V
Data Resolution 0 to 4,095
Input Impedance Approx. 100 kΩ
Error ±1% of full scale (±5% of full scale when noise is applied)
